2005 Harley-Davidson Softail Supplement B – All 16 Sections Set
Every SPB section file, one purchase
Supplement B for the 2005 Softail runs to 16 section files, and this is all of them in one purchase. A supplement records what differs on particular models, so it is read next to the base service manual rather than on its own.
What’s included
This set is Harley-Davidson’s FLSTFSE Service Supplement, part number 99494-05: 112 pages in nine sections. Each section comes as a one-page contents file (the _TC file) plus the section itself, so you can open just the system you are working on.
| Section 1: Maintenance (4 pages) | |
|---|---|
| Engine oil for the factory Screamin’ Eagle SYN3 synthetic fill, including what H-D says to top up with when SYN3 is not available. Air cleaner removal and refit with fastener torques. Checking and correcting the hydraulic clutch fluid level (DOT 5 silicone). |
|
| Section 2: Chassis (about 34 pages) | |
| FLSTFSE dimensions, weights, tire sizes and cold pressures, fluid capacities, chassis torque values and the VIN code table. Service procedures for the front and rear wheels and axle covers, rear brake pads, front spoiler, handgrips and hand controls, handlebars, rear fork pivot covers and seat, plus the hydraulic clutch master cylinder, hand lever and clutch fluid line, including bleeding the clutch. |
|
| Section 3: Engine (about 26 pages) | |
| Specifications for the 103 cu in (1690 cc) engine: 3.875 in bore, 4.375 in stroke, 9.0:1 compression and 100 ft-lb of torque at 3500 rpm. Engine torque values and service wear limits, then head bolt covers, cylinder heads, rocker housing, pistons and connecting rods, boring and honing, cams and timing marks, and the counterbalancer, which runs roller bearings on the sprocket-end balance shaft instead of the ball bearings used in other Softail engines. |
|
| Section 4: Fuel System (contents page only) | |
| No FLSTFSE-specific content. Harley-Davidson’s note on this page sends you to the Softail Models Service Manual for all fuel system work. |
|
| Section 5: Electric Starter (1 page) | |
| Specification table for the 1.4 kW starter: free (no load) speed, free current and stall torque test values. |
|
| Section 6: Drive (2 pages) | |
| Primary chaincase lubricant amount and part number, and FLSTFSE clutch release bearing removal and installation, including the release plate movement check after bleeding. |
|
| Section 7: Transmission (about 6 pages) | |
| Transmission data for the 5-speed gearbox on SYN3, transmission torque values, the clutch release cover, the secondary clutch actuator that the hydraulic clutch line operates, with its bleeding procedure, and the clutch release bearing and pushrod. |
|
| Section 8: Electrical (about 20 pages) | |
| Electrical torque values, turn signals, handlebar wiring, tachometer and speedometer. Diagnostic flow charts for tachometer codes P1653 and P1654 with the tachometer circuit and connector table, the tachometer inoperative check, the voltage regulator and the spoiler/regulator bracket. |
|
| Section 9: Fuel Injection (contents page only) | |
| No FLSTFSE-specific content. Harley-Davidson notes that every fuel injection procedure in the Softail Models Service Manual applies, with diagnostics in the Softail Electrical Diagnostic Manual. |
