2013 Harley-Davidson Dyna Electrical Diagnostic Manual (99496-13)
Factory publication 99496-13, digitized
Electrical work needs a different book from mechanical work. The 2013 Harley-Davidson Dyna Electrical Diagnostic Manual (99496-13) is that book, and this is the factory copy as a PDF for $29.95. Harley-Davidson published it separately from the service manual, so it is sold separately here.
What’s included
- Electrical Diagnostic Manual
Every item above arrives as its own download link.
Who buys this and why
Anyone chasing a fault with a meter instead of replacing parts and hoping. Dealer diagnostic time runs well past the $29.95 this costs.
Specifications
| Publication type | Factory electrical diagnostics |
| Model year | 2013 |
| Part number | 99496-13 |
| Model family | Dyna |
| File format | |
| Price | $29.95, reduced to $16.95 until 7 September 2026 |
| Files included | 1 |
| Models covered | Super Glide (FXD/FXDC), Street Bob (FXDB), Low Rider (FXDL), Wide Glide (FXDWG), Fat Bob (FXDF, 2008+), Switchback (FLD, 2012+) |
| Engine | Twin Cam 96 / 103 |
Overview
Harley-Davidson documents wiring and electrical fault-tracing in a separate volume from the service manual. This is that volume for the 2013 Dyna line, in PDF.
One file, delivered complete. Source document: Harley-Davidson part number 99496-13.
What this is not
This volume covers electrical diagnosis only. Engine, chassis and drivetrain procedures are in the service manual (SKU HD-99481-13A, $18.95).
Delivery
Link on the order confirmation page and by email, no account needed. 25 downloads over 25 days; email [email protected] with your order number for a resend.
How this file is used
Electrical faults get chased with a meter, usually with panels off and the bike half apart. Print the circuit pages rather than reading them on a screen in a dark garage. 25 downloads over 25 days for the 2013 Dyna electrical book.
Also published for this model year
Also for the 2013 Dyna: Service Manual (99481-13A) $18.95; Service Manual + Electrical Diagnostics Bundle $24.95.
Common questions
Which bikes does this cover?
What do I need to open it?
Does this replace the service manual?
This is one of 62 Dyna publications in our catalogue, covering model years 1991 to 2017. Buying more than one year of documentation for the same machine is common when a bike has been rebuilt with parts from several model years.
